Русский20ft Ultra-Slim (700mm) Double-Wing Folding House
20ft ultra-slim double-wing folding house with a 700 mm folded profile for freight-sensitive projects. The unit expands on site for compact accommodation, offices or hospitality use; confirm the final loading plan and configuration for each project.
20ft Ultra-Slim (700mm) Double-Wing Folding House
The 20ft Ultra-Slim Double-Wing Folding House collapses to approximately 700 mm thick while retaining a 5900 mm transport length. It expands on site to a compact modular space for accommodation, offices or hospitality use. The galvanized steel frame and project-ready utility layout support shipping-sensitive B2B orders; confirm the final loading plan and configuration for each project.
Product Description
The 20ft Ultra-Slim Double-Wing Folding House is optimized for freight-sensitive orders: it folds to approximately 700 mm thick while retaining a 5900 mm transport length. It expands on site for compact accommodation, offices or hospitality use; confirm the final loading plan and configuration for each project.
Key Features
Compact Folded Design
Folds down to a slim profile for economical transport — lowers logistics cost and simplifies handling.
Double-Wing Expansion
Two wings unfold on-site to deliver a much larger usable interior than a standard container of the same length.
Flat Roof Design
Modern, clean exterior with efficient space usage and easy maintenance.
Durable Steel Frame
Frame and panel specifications can be reviewed with the supplier for the selected model.
Custom Interior Layout
Partitions, storage, kitchen, and bathroom zones can all be tailored to your project requirements.
Water & Electric Ready
Prepared wiring and plumbing interfaces for quick connection to local utility systems.
Customizable Exterior
Exterior finishes and configurations can be adapted to different market requirements.
Flexible Room Combo
Room, bathroom and kitchen layouts can be discussed based on the selected model and project requirements.
Shipping Planning
Loading plans can be reviewed with the supplier based on the selected size and project quantity.
Specifications
Basic Specifications | |
|---|---|
External Dimensions (mm) | 5900*4800*2480 |
Internal Dimensions (mm) | 5740*4640*2200 |
Folded Dimensions (mm) | 5900*700*2480 |
Total Weight (kg) | 2.3t |
Frame Structure | |
|---|---|
Middle Top Beam | 80*100*T2.5mm |
Middle Bottom Beam | 80*140*T2.5mm |
End Side Beams | T2.0mm Z-shaped bent part |
Middle Columns | 150*210*T2.5mm |
Side Wall Frame | 40*80*T1.2mm |
Side Bottom Purlins | 40*60*T1.2mm |
Middle Bottom & Top Purlins | 40*80*T1.2mm |
Side Top Frame | 40*80*T1.2mm |
Folding Hinges | 13mm galvanized hinges |
Overall Frame Protective Coating | Electrostatic spraying / pure white plastic powder |
Lifting Head | T6.25mm |
Roof | |
|---|---|
External Roof Panel | T50mm EPS |
Internal Ceiling | T193 internal ceiling |
Side Roof Panels | T50mm EPS |
Wall Panels | |
|---|---|
Side Walls, Front & Back Walls | T65mm EPS |
Internal Partition Panels | T50mm EPS |
Wall Panel Steel Sheet Thickness | Double-sided 0.3mm |
Floor | |
|---|---|
Middle Floor | Calcium silicate floor 18mm |
Side Floors | Calcium silicate floor 18mm |
Customizable Floor Plans
Partition positions, door/window locations, and kitchen & bathroom zones can all be customized to your drawings. Contact us with your target layout for a free plan check and quote.
Applications
Dealers & Distributors
Regional resale stock and project tender supply.
EPC & Construction Teams
Worker accommodation and on-site project management offices.
Hotel Operators
Glamping extensions, staff dormitories, and seasonal capacity.
Public Sector Buyers
Community temporary housing and emergency planning.
Relief & NGO Projects
Rapid-deploy shelters and support camps.
Commercial Operators
Pop-up service rooms, kiosks, training spaces, and site offices.
Private Owners
Backyard granny flats, rental units, home offices, and compact living.
Project Coordination
We coordinate modular housing sourcing with suitable supplier resources and provide product information for international projects. Share your target layout, local requirements, and delivery destination for a tailored recommendation.
10 / 20 / 30 / 40 ft
Size Options
19.1–72 m²
Reference Floor Areas
12 kW
Standard Electrical Load
On Request
Technical Documents
FAQ
What information is needed for a fast quote?
Can a dealer sell the same model to different customers?
How is water and electricity connected on-site?
Is it suitable for bulk purchase and repeat projects?
